Tough and Ready for the Field
IP67 Dustproof and WaterproofTo ensure safety, use the optional Test Lead L9787 when making measurements using the two-electrode method.
Measurement system Two-electrode method/three-electrode method (switchable)
Measurement range 20 Ω (0 Ω〜20.00 Ω) 200 Ω (0 Ω〜200.0 Ω) 2000 Ω (0 Ω〜2000 Ω)
Accuracy ±1.5% rdg ±8 dgt ±1.5% rdg ±4 dgt ±1.5% rdg ±4 dgt
Earth voltage 0〜30.0 V rms
Accuracy: ±2.3% rdg ±8 dgt (50 Hz/60 Hz), ±1.3% rdg ±4 dgt (DC)
Allowable earth potential 25.0 V rms (DC or sine wave)
Dustproof and waterproof IP65/IP67 (EN60529)
Power supply LR6 Alkaline battery ×4, Possible number of measurements: 500 times (measurement conditions: three-electrode method, measuring 10 Ω at 10-second intervals without Z3210 installed)
Functions Live wire warning, zero-adjustment, continuous measurement mode, wireless communication (only when Z3210 is connected), and comparator
