ASTM C-39
Frame : Heavy-duty welded steel contruction 30 cm profile steel columns 10 cm thick botom and upper and upper plate
Hydraulic System : Mild-Steel cylinder,
For 3000 kN Cap : Hard-chormed piston, 250 mm dia max working pressure 50.000 kPa Overal dimension 330 mm dia x 320 mm height. Single action, gravity return
Hydraulic Pump : Electric, 220 V AC, 50-60 Hz, 1000 Watt,1 Phase single action, variable speed 6.000 ml reservoir cap max working pressure 50.000 kPa. Single action, gravity return.
Digital Force Gauge : Steel box housing. Display indicator 6 digit. Power Supply 6 Volt DC. Include Pressure Tranducer. Battery Output 6 Volt DC. Calibrated by KAN.
Print Out : AC DC 5V 3A. 15 Watt. Satuan kN. Manual Print. Manual Cutter Paper.
Compressive : Upper : 180 x 180 mm, ball seating.
Platen : Lower : 250 mm dia
Clearance : Horizontal : 290 mm Vertical : 310 mm
Dimension : 760 x 320 x 1400 mm
Weight : ( l x w x h ) approx. 700 kg
